作者 | JiekeXu

来源 |公众号 JiekeXu DBA之路（ID: JiekeXu_IT）

大家好，我是 JiekeXu,很高兴又和大家见面了,今天和大家一起来看看 Oracle ADG 备库停启维护流程及增量恢复，欢迎点击上方蓝字关注我，标星或置顶，更多干货第一时间到达！

对于 Oracle Oracle ADG 备库重启时有些人都会有一个小问题，那就是没有及时应用日志没启动 MRP0 进程，导致主备库不同步。一般情况下主备库不同步的原因有：

主库 SYS 密码改变而未同步密码文件到备库
主库或者备库归档空间满无法归档
主库或者备库监听异常，无法通过网络连接到主备库
主库相关参数改变导致无法和备库正常同步
主备库 tnsnames sqlnet listener 等文件改变
备库未开启日志应用进程
备库磁盘空间不足等等其他原因。

而这些原因大多数都可以通过查看主备库的 alter 告警日志展现出来，或者在主库查看视图 V$ARCHIVE_DEST。

SELECT DEST_ID, STATUS, APPLIED_SCN,ERROR FROM V$ARCHIVE_DEST WHERE TARGET='STANDBY';

一、ADG 备库停启维护步骤

下面来看一下ADG 备库停启维护流程(以 11g 为例)。

1、停备库应用

如果备库有查询等的只读业务，最好可以先停止相关业务。

查看备库保护模式

select DATABASE_ROLE,PROTECTION_MODE,PROTECTION_LEVEL from v$database;
DATABASE_ROLE    PROTECTION_MODE      PROTECTION_LEVEL---------------- -------------------- --------------------PHYSICAL STANDBY MAXIMUM PERFORMANCE  MAXIMUM PERFORMANCE

Maximum performance：最大性能模式
默认的保护模式；在不影响主库性能的情况下，提供最高级别的保护模式。
Maximum protection ：最大保护模式
保证备库的内容和主库的内容完全一致，不能有丝毫的差别；保证当主库出现问题，不会有任何的数据丢失；为了达到这样的保护级别，redo data 必须同时写入主库的 online redo log和备库的 standby redo log；一旦备库的日志写入不成功，那么，主库 hang 住，超过某个时间长度，主库自动停止实例；
Maximum availability：最大可用模式
介于最大保护和最大性能之间的一种模式：一般使用最大保护模式保护主库，一旦达不到最大保护模式的条件，转为最大性能模式；要求所有事务在提交前必须保障 redo 数据至少在一个 standby 数据库可用，不过与之不同的是，如果出现故障导入无法同时写入standby 数据库 redo log，primary 数据库并不会 shutdown，而是自动转为最大性能模式，等 standby 数据库恢复正常之后，它又会再自动转换成最大可用性模式。

2、先停监听,杀会话

lsnrctl statuslsnrctl stopps -ef | grep LOCAL=NO | grep -v grep | awk '{print $2}' |wc -l ps -ef | grep LOCAL=NO | grep -v grep | awk '{print $2}' | xargs kill -9 ps -ef | grep LOCAL=NO | grep -v grep | awk '{print $2}' |wc -l

3、ADG备库检查、停备库

sqlplus / as sysdba--查看同步情况set linesize 150; set pagesize 9999; column name format a13; column value format a20; column unit format a30; column TIME_COMPUTED format a30; select name,value,unit,time_computed from v$dataguard_stats where name in ('transport lag','apply lag');
select open_mode from v$database;select process,status,sequence# from v$managed_standby;

主备库查看归档路径

column destination format a50 column process format a7column ID format 99column mid format 99SELECT thread#, dest_id, destination, gvad.status, target, schedule, process, mountid mid FROM gv$archive_dest gvad, gv$instance gvi WHERE gvad.inst_id = gvi.inst_id AND destination is NOT NULLORDER BY thread#, dest_id;
   THREAD#    DEST_ID DESTINATION                                        STATUS    TARGET  SCHEDULE PROCESS MID---------- ---------- -------------------------------------------------- --------- ------- -------- ------- ---         1          1 +FRA                                               VALID     PRIMARY ACTIVE   ARCH      0         1          2 jieket4dg                                           VALID     STANDBY ACTIVE   LGWR      0         1          3 jiekeyun                                            DEFERRED  STANDBY PENDING  LGWR      0         2          1 +FRA                                               VALID     PRIMARY ACTIVE   ARCH      0         2          2 jieket4dg                                           VALID     STANDBY ACTIVE   LGWR      0         2          3 jiekeyun                                            DEFERRED  STANDBY PENDING  LGWR      0         3          1 +FRA                                               VALID     PRIMARY ACTIVE   ARCH      0         3          2 jieket4dg                                           VALID     STANDBY ACTIVE   LGWR      0         3          3 jiekeyun                                            DEFERRED  STANDBY PENDING  LGWR      0         4          1 +FRA                                               VALID     PRIMARY ACTIVE   ARCH      0         4          2 jieket4dg                                           VALID     STANDBY ACTIVE   LGWR      0         4          3 jiekeyun                                            DEFERRED  STANDBY PENDING  LGWR      0
12 rows selected.
--备库查看
   THREAD#    DEST_ID DESTINATION                                        STATUS    TARGET  SCHEDULE PROCESS MID---------- ---------- -------------------------------------------------- --------- ------- -------- ------- ---         1          1 /data/jxrtt4dg/arch                                VALID     LOCAL   ACTIVE   ARCH      0         1          2 jxr2p                                              VALID     REMOTE  PENDING  LGWR      0         1         32 /data/jxrtt4dg/arch                                VALID     LOCAL   ACTIVE   RFS       0

关库

sqlplus / as sysdbashutdown immediate;exit;
--查看 alter 日志tail -50f alert_jiekedb.log

4.主机关机维护，等待完毕后开机

shutdown -h now

注意：如果主机关机维护过程时间比较长，导致主库的归档日志已经被删除了而且也没有备份归档，则只能全量恢复或者增量恢复备库了,所以维护前需要调整归档删除策略来避免归档被删除。

5.启动 ADG 备库

先查看是否已启动

su - oracleps -ef | grep smon lsnrctl statussqlplus / as sysdba

如果已启动，检查数据库启动到哪个阶段

col HOST_NAME for a30 select INSTANCE_NAME,HOST_NAME,VERSION,STARTUP_TIME,STATUS from gv$instance;

如果没有启动,则先启动到 mount

sqlplus / as sysdbastartup mount select open_mode from v$database;

检查 mrp0 进程是否开启

select process,status,sequence#,THREAD# from v$managed_standby where PROCESS='MRP0';
PROCESS STATUS        SEQUENCE#    THREAD#------- ------------ ---------- ----------MRP0    APPLYING_LOG       4764          4

检查 ADG 同步情况

set linesize 150; set pagesize 9999; column name format a13; column value format a20; column unit format a30; column TIME_COMPUTED format a30; select name,value,unit,time_computed from v$dataguard_stats where name in ('transport lag','apply lag');

--如果没有开启则先开启 mrp0 进程，使用如下语句应用日志进程 mrp0alter database recover managed standby database using current logfile disconnect;

再次查看等如下 value 值为0

set linesize 150; set pagesize 9999; column name format a13; column value format a20; column unit format a30; column TIME_COMPUTED format a30; select name,value,unit,time_computed from v$dataguard_stats where name in ('transportlag','apply lag');

取消日志应用

alter database recover managed standby database cancel;

然后 open 数据库实例

alter database open;
select open_mode from v$database;

然后需要继续应用日志进程 mrp0

alter database recover managed standby database using current logfile disconnect;
--检查 mrp0 进程select process,status,sequence#,THREAD# from v$managed_standby;
--查看日志应用时间，注意 apply lag 即可。set linesize 150; set pagesize 9999; column name format a13; column value format a20; column unit format a30; column TIME_COMPUTED format a30; select name,value,unit,time_computed from v$dataguard_stats where name in ('transport lag','apply lag');
SELECT AL.THRD "Thread",       ALMAX   "Last Seq Received",       LHMAX   "Last Seq Applied"  FROM (SELECT THREAD# THRD, MAX(SEQUENCE#) ALMAX          FROM V$ARCHIVED_LOG         WHERE RESETLOGS_CHANGE# =               (SELECT RESETLOGS_CHANGE# FROM V$DATABASE)         GROUP BY THREAD#) AL,       (SELECT THREAD# THRD, MAX(SEQUENCE#) LHMAX          FROM V$LOG_HISTORY         WHERE RESETLOGS_CHANGE# =               (SELECT RESETLOGS_CHANGE# FROM V$DATABASE)         GROUP BY THREAD#) LH WHERE AL.THRD = LH.THRD;

6、验证主备同步性

主库切换日志检查备库日志是否会立即同步

alter system switch logfile;
alter system archive log current;

备库查看 Alert 日志更新情况
tail -500f alert_jiekedb.log

二、备库基于 SCN 增量恢复

备库由于前面提到的更改主库 SYS 密码忘记同步密码文件到备库导致备库已经十多天不同步了，由于此库属于非生产库，没有备份更没有备份归档，恢复归档的方法这里就不能用了，故只能选择全库恢复或者基于 SCN 增量恢复，这里选择增量恢复。关于 ADG 备库恢复的前面也有一份手册，需要的可点此查看。

1、查看备库当前 SCN

以备库当前 SCN 为时间点，在主库上基于此 SCN 做增量备份，然后恢复到备库，再应用当前日志即可正常同步备库。

sqlplus / as sysdbaselect  to_char(current_scn) from v$database;TO_CHAR(CURRENT_SCN)----------------------------------------11381638776

这里查到备库的 SCN （最好是最小 SCN）之后，需要到主库查看基于此 SCN 号之后是否有新增数据文件，新增的数据文件无法通过增量恢复，必须先恢复数据文件之后方可增量恢复。

2、主库备份控制文件传到备库恢复

alter database create standby controlfile as '/tmp/t4_standby.ctl';
scp /tmp/t4_standby.ctl 到备库 /tmp/t4_standby.ctl。

3、重启备库

shu immediate startup nomount

4、备库 rman 恢复控制文件

rman target /restore controlfile from '/tmp/t4_standby.ctl';

5、备库启动到 mount

RMAN> sql 'alter database mount';

6、主库基于 SCN 增量备份 11381638776

run{allocate channel c1 type disk;allocate channel c2 type disk;backup INCREMENTAL from scn 11381638776 database format '/nfs/backup/incre_%U';release channel c1;release channel c2;}

7、增量备份传到备库 /data/backup/ 并注册 catalog

scp -r /nfs/backup/incre* 到备库 /data/backup/
RMAN> catalog start with '/data/backup/';

8、recover 恢复备库

使用recover database noredo 即可恢复，但是可惜的是我这里报错了。

RMAN> recover database noredo;
Starting recover at 2022-01-24 16:25:58using channel ORA_DISK_1RMAN-00571: ===========================================================RMAN-00569: =============== ERROR MESSAGE STACK FOLLOWS ===============RMAN-00571: ===========================================================RMAN-03002: failure of recover command at 01/24/2022 16:25:59RMAN-06094: datafile 26 must be restored
RMAN> recover database noredo;
Starting recover at 2022-01-24 16:30:45using channel ORA_DISK_1RMAN-00571: ===========================================================RMAN-00569: =============== ERROR MESSAGE STACK FOLLOWS ===============RMAN-00571: ===========================================================RMAN-03002: failure of recover command at 01/24/2022 16:30:45RMAN-06094: datafile 26 must be restored

三、排查问题及解决

1、主库查看基于 SCN 后是否有新增文件

select file#,name from v$datafile where creation_change#> =11381638776;
SQL> select file#,to_char(creation_time,'yyyy-mm-dd hh24:mi:ss' ) creation_time,status,last_time,name from v$datafile     where creation_change#>11381638776;
no rows selected

但是通过这个 SQL 查不到，证明基于此 SCN 没有新增数据文件。但前面 26 号却是实实在在得报错了，百思不得其解，大于 26 号文件的还有 27 、28 号文件。

查看 alter 日志

grep -A 4 "alter database datafile 27" alert_jie2p1.log
alter database datafile 27 resize 30gCompleted: alter database datafile 27 resize 30gThu Dec 30 14:47:56 2021alter database datafile 27 resize 32767mCompleted: alter database datafile 27 resize 32767m
--添加 28 号数据文件记录。
alter tablespace JIEKE_DATA add datafile '+DATA' size 32767MWed Jan 05 19:46:36 2022Completed: alter tablespace JIEKE_DATA add datafile '+DATA' size 32767MWed Jan 05 19:47:52 2022

查看 alter 日志此三个数据文件也是在修改主库密码文件前添加的，所以不属于新增的数据文件。

查看这三个文件创建时间

col name for a69select file#,name,CREATION_TIME from v$datafile where file#>=26;    FILE# NAME                                                                  CREATION_TIME---------- --------------------------------------------------------------------- -------------------        26 +DATA/jie2p/datafile/t4_ccdb_data.313.1083605453                     2021-09-18 17:31:09        27 +DATA/jie2p/datafile/jieke_data.314.1087482763                       2021-11-01 14:32:57        28 +DATA/jie2p/datafile/jieke_data.323.1093203957                       2022-01-05 19:46:35

查看生成的备库控制文件中确实存在如上的三个数据文件，说明控制文件恢复的也没有问题。

strings t4standby.ctl | grep jieke_data.323.1093203957

备库通过 report schema; 查看 Size 大小为 0，“Datafile Name” 列的路径下没有数据文件，说明这三个文件存在问题。

RMAN> report schema;
RMAN-06139: WARNING: control file is not current for REPORT SCHEMAReport of database schema for database with db_unique_name JIEKET4DG
List of Permanent Datafiles===========================File Size(MB) Tablespace           RB segs Datafile Name---- -------- -------------------- ------- ------------------------1    30720    SYSTEM               ***     /data/jieket4dg/datafile/system.260.10164685192    32704    SYSAUX               ***     /data/jieket4dg/datafile/sysaux.306.10164687633    10240    UNDOTBS1             ***     /data/jieket4dg/datafile/undotbs1.270.10164686994    3557     USERS                ***     /data/jieket4dg/datafile/users.264.10164685975    32704    JIEKE_DATA           ***     /data/jieket4dg/datafile/jieke_data.261.10164685176    20480    JIEKE_INDEX          ***     /data/jieket4dg/datafile/jieke_index.262.10164685957    5120     JIEKE_DAT            ***     /data/jieket4dg/datafile/jieke_dat.256.10164685218    1024     PROD_YD_DATA         ***     /data/jieket4dg/datafile/prod_yd_data.257.10164686979    1024     PROD_YD_INDEX        ***     /data/jieket4dg/datafile/prod_yd_index.305.101646876510   5120     PROD_MOBISCF_DATA    ***     /data/jieket4dg/datafile/prod_mobiscf_data.269.101646859511   5120     PROD_MOBISCF_INDEX   ***     /data/jieket4dg/datafile/prod_mobiscf_index.304.101646876712   5120     PROD_DBSZ_DATA       ***     /data/jieket4dg/datafile/prod_dbsz_data.295.101646852113   5120     PROD_DBSZ_INDEX      ***     /data/jieket4dg/datafile/prod_dbsz_index.277.101646870114   29696    SYSAUX               ***     /data/jieket4dg/datafile/sysaux.265.101646859115   29696    SYSAUX               ***     /data/jieket4dg/datafile/sysaux.274.101646870116   10240    UNDOTBS2             ***     /data/jieket4dg/datafile/undotbs02.dbf17   10240    UNDOTBS3             ***     /data/jieket4dg/datafile/undotbs03.dbf18   10240    UNDOTBS4             ***     /data/jieket4dg/datafile/undotbs04.dbf19   1400     PROD_SCFOP_TBS       ***     /data/jieket4dg/datafile/prod_scfop_tbs.300.103788114320   2048     USERS                ***     /data/jieket4dg/datafile/users.307.104532571521   100      TEST_PY_DATA         ***     /data/jieket4dg/datafile/test_py_data.308.105742671722   32767    JIEKE_DATA           ***     /data/jieket4dg/datafile/jieke_data.309.106798034723   500      ITSM_AUTO_TEST1_DATA ***     /data/jieket4dg/datafile/itsm_auto_test1_data.310.107200614524   500      ITSM_AUTO_TEST2_DATA ***     /data/jieket4dg/datafile/itsm_auto_test2_data.311.107200646125   1824     OGG_TBS              ***     /data/jieket4dg/datafile/ogg_tbs.312.108074808326   0        T4_ccdb_DATA         ***     /data/jieket4dg/datafile/t4_ccdb_data.313.108360545327   0        JIEKE_DATA           ***     /data/jieket4dg/datafile/jieke_data.314.108748276328   0        JIEKE_DATA           ***     /data/jieket4dg/datafile/jieke_data.323.1093203957
List of Temporary Files=======================File Size(MB) Tablespace           Maxsize(MB) Tempfile Name---- -------- -------------------- ----------- --------------------2    5120     TEMP                 5120        /data/jieket4dg/tempfile/temp.273.1016480467

事后本想通过前面查询到的 SCN 反查当时时间，但遗憾的是在主备库查询均报错了。这是由于最小的 SCN 号也已经超过了此 SCN，故无法进行相互转换了，如下所示：

SQL> select to_char(scn_to_timestamp('11381638776'),'yyyy-mm-dd hh24:mi:ss') scndate from dual;select to_char(scn_to_timestamp('11381638776'),'yyyy-mm-dd hh24:mi:ss') scndate from dual               *ERROR at line 1:ORA-08181: specified number is not a valid system change numberORA-06512: at "SYS.SCN_TO_TIMESTAMP", line 1
SQL> col min_scn  for 99999999999999999999SQL> select min(SCN) min_scn from sys.smon_scn_time;
              MIN_SCN---------------------          11735387827
Elapsed: 00:00:00.00SQL> select to_char(scn_to_timestamp(11735387827), 'yyyy-mm-dd hh24:mi:ss') scndate from dual;
SCNDATE-------------------2022-02-03 00:25:10

既然这三个数据文件有问题，那么就按照新增数据文件或者修改数据文件的方式去处理，则在主库备份这几个新增数据文件然后在备库恢复，在接着做增量恢复就行。

2、主库备份新增数据文件26 27 28

RMAN> run{allocate channel c1 type disk;2> 3> allocate channel c2 type disk;4> backup datafile 26,27,28  format '/nfs/backup/incre_dbfile_%U';5> release channel c1;6> release channel c2;}7>

3、scp 传到备库恢复

scp /nfs/backup/incre_dbfile* 到备库 /data/backup/dbfilerman target /catalog start with '/data/backup/dbfile';
RMAN> run{2> set newname for datafile  26 to '/data/jieket4dg/datafile/t4_ccdb_data.313.1083605453';3> set newname for datafile  27 to '/data/jieket4dg/datafile/jieke_data.314.1087482763';4> set newname for datafile  28 to '/data/jieket4dg/datafile/jieke_data.323.1093203957';5> restore datafile 26,27,28;}
executing command: SET NEWNAME
executing command: SET NEWNAME
executing command: SET NEWNAME
Starting restore at 2022-01-24 17:44:42using channel ORA_DISK_1
channel ORA_DISK_1: starting datafile backup set restorechannel ORA_DISK_1: specifying datafile(s) to restore from backup setchannel ORA_DISK_1: restoring datafile 00026 to /data/jieket4dg/datafile/t4_ccdb_data.313.1083605453channel ORA_DISK_1: restoring datafile 00027 to /data/jieket4dg/datafile/jieke_data.314.1087482763channel ORA_DISK_1: reading from backup piece /data/backup/dbfile/incre_dbfile_1p0k3nsi_1_1channel ORA_DISK_1: piece handle=/data/backup/dbfile/incre_dbfile_1p0k3nsi_1_1 tag=TAG20220124T170834channel ORA_DISK_1: restored backup piece 1channel ORA_DISK_1: restore complete, elapsed time: 00:05:35channel ORA_DISK_1: starting datafile backup set restorechannel ORA_DISK_1: specifying datafile(s) to restore from backup setchannel ORA_DISK_1: restoring datafile 00028 to /data/jieket4dg/datafile/jieke_data.323.1093203957channel ORA_DISK_1: reading from backup piece /data/backup/dbfile/incre_dbfile_1q0k3nsi_1_1channel ORA_DISK_1: piece handle=/data/backup/dbfile/incre_dbfile_1q0k3nsi_1_1 tag=TAG20220124T170834channel ORA_DISK_1: restored backup piece 1channel ORA_DISK_1: restore complete, elapsed time: 00:02:05Finished restore at 2022-01-24 17:52:23
RMAN> report schema;
RMAN-06139: WARNING: control file is not current for REPORT SCHEMAReport of database schema for database with db_unique_name jiekeT4DGList of Permanent Datafiles===========================File Size(MB) Tablespace           RB segs Datafile Name---- -------- -------------------- ------- ------------------------1    30720    SYSTEM               ***     /data/jieket4dg/datafile/system.260.10164685192    32704    SYSAUX               ***     /data/jieket4dg/datafile/sysaux.306.10164687633    10240    UNDOTBS1             ***     /data/jieket4dg/datafile/undotbs1.270.10164686994    3557     USERS                ***     /data/jieket4dg/datafile/users.264.10164685975    32704    jieke_DATA          ***     /data/jieket4dg/datafile/jieke_data.261.10164685176    20480    jieke_INDEX         ***     /data/jieket4dg/datafile/jieke_index.262.10164685957    5120     jieke_DAT             ***     /data/jieket4dg/datafile/jieke_dat.256.10164685218    1024     PROD_YD_DATA         ***     /data/jieket4dg/datafile/prod_yd_data.257.10164686979    1024     PROD_YD_INDEX        ***     /data/jieket4dg/datafile/prod_yd_index.305.101646876510   5120     PROD_MOBISCF_DATA    ***     /data/jieket4dg/datafile/prod_mobiscf_data.269.101646859511   5120     PROD_MOBISCF_INDEX   ***     /data/jieket4dg/datafile/prod_mobiscf_index.304.101646876712   5120     PROD_dbsz_DATA      ***     /data/jieket4dg/datafile/prod_dbsz_data.295.101646852113   5120     PROD_dbsz_INDEX     ***     /data/jieket4dg/datafile/prod_dbsz_index.277.101646870114   29696    SYSAUX               ***     /data/jieket4dg/datafile/sysaux.265.101646859115   29696    SYSAUX               ***     /data/jieket4dg/datafile/sysaux.274.101646870116   10240    UNDOTBS2             ***     /data/jieket4dg/datafile/undotbs02.dbf17   10240    UNDOTBS3             ***     /data/jieket4dg/datafile/undotbs03.dbf18   10240    UNDOTBS4             ***     /data/jieket4dg/datafile/undotbs04.dbf19   1400     PROD_SCFOP_TBS       ***     /data/jieket4dg/datafile/prod_scfop_tbs.300.103788114320   2048     USERS                ***     /data/jieket4dg/datafile/users.307.104532571521   100      TEST_PY_DATA         ***     /data/jieket4dg/datafile/test_py_data.308.105742671722   32767    jieke_DATA          ***     /data/jieket4dg/datafile/jieke_data.309.106798034723   500      ITSM_AUTO_TEST1_DATA ***     /data/jieket4dg/datafile/itsm_auto_test1_data.310.107200614524   500      ITSM_AUTO_TEST2_DATA ***     /data/jieket4dg/datafile/itsm_auto_test2_data.311.107200646125   1824     OGG_TBS              ***     /data/jieket4dg/datafile/ogg_tbs.312.108074808326   10240    T4_ccdb_DATA         ***     /data/jieket4dg/datafile/t4_ccdb_data.313.108360545327   32767    jieke_DATA          ***     /data/jieket4dg/datafile/jieke_data.314.108748276328   32767    jieke_DATA          ***     /data/jieket4dg/datafile/jieke_data.323.1093203957
List of Temporary Files=======================File Size(MB) Tablespace           Maxsize(MB) Tempfile Name---- -------- -------------------- ----------- --------------------2    5120     TEMP                 5120        /data/jieket4dg/tempfile/temp.273.1016480467

4、恢复完数据文件重新注册 catalog 增量恢复备库

RMAN> catalog start with '/data/backup';
using target database control file instead of recovery catalogsearching for all files that match the pattern /data/backupno files found to be unknown to the database
RMAN> list incarnation;

List of Database IncarnationsDB Key  Inc Key DB Name  DB ID            STATUS  Reset SCN  Reset Time------- ------- -------- ---------------- --- ---------- ----------1       1       JXR2P    3857716255       PARENT  1          2013-08-24 11:37:302       2       JXR2P    3857716255       PARENT  925702     2017-10-16 14:48:013       3       JXR2P    3857716255       CURRENT 671821825  2019-08-16 19:27:10
RMAN> recover database noredo;Starting recover at 2022-01-24 18:00:21allocated channel: ORA_DISK_1channel ORA_DISK_1: SID=572 device type=DISKchannel ORA_DISK_1: starting incremental datafile backup set restorechannel ORA_DISK_1: specifying datafile(s) to restore from backup setdestination for restore of datafile 00001: /data/jieket4dg/datafile/system.260.1016468519destination for restore of datafile 00006: /data/jieket4dg/datafile/jieke_index.262.1016468595destination for restore of datafile 00011: /data/jieket4dg/datafile/prod_mobiscf_index.304.1016468767destination for restore of datafile 00013: /data/jieket4dg/datafile/prod_dbsz_index.277.1016468701destination for restore of datafile 00014: /data/jieket4dg/datafile/sysaux.265.1016468591destination for restore of datafile 00017: /data/jieket4dg/datafile/undotbs03.dbfdestination for restore of datafile 00019: /data/jieket4dg/datafile/prod_scfop_tbs.300.1037881143destination for restore of datafile 00020: /data/jieket4dg/datafile/users.307.1045325715destination for restore of datafile 00021: /data/jieket4dg/datafile/test_py_data.308.1057426717destination for restore of datafile 00023: /data/jieket4dg/datafile/itsm_auto_test1_data.310.1072006145destination for restore of datafile 00024: /data/jieket4dg/datafile/itsm_auto_test2_data.311.1072006461channel ORA_DISK_1: reading from backup piece /data/backup/incre_1m0k3ibg_1_1channel ORA_DISK_1: piece handle=/data/backup/incre_1m0k3ibg_1_1 tag=TAG20220124T153407channel ORA_DISK_1: restored backup piece 1channel ORA_DISK_1: restore complete, elapsed time: 00:04:35channel ORA_DISK_1: starting incremental datafile backup set restorechannel ORA_DISK_1: specifying datafile(s) to restore from backup setdestination for restore of datafile 00002: /data/jieket4dg/datafile/sysaux.306.1016468763destination for restore of datafile 00003: /data/jieket4dg/datafile/undotbs1.270.1016468699destination for restore of datafile 00004: /data/jieket4dg/datafile/users.264.1016468597destination for restore of datafile 00005: /data/jieket4dg/datafile/jieke_data.261.1016468517destination for restore of datafile 00007: /data/jieket4dg/datafile/jieke_dat.256.1016468521destination for restore of datafile 00008: /data/jieket4dg/datafile/prod_yd_data.257.1016468697destination for restore of datafile 00009: /data/jieket4dg/datafile/prod_yd_index.305.1016468765destination for restore of datafile 00010: /data/jieket4dg/datafile/prod_mobiscf_data.269.1016468595destination for restore of datafile 00012: /data/jieket4dg/datafile/prod_dbsz_data.295.1016468521destination for restore of datafile 00015: /data/jieket4dg/datafile/sysaux.274.1016468701destination for restore of datafile 00016: /data/jieket4dg/datafile/undotbs02.dbfdestination for restore of datafile 00018: /data/jieket4dg/datafile/undotbs04.dbfdestination for restore of datafile 00022: /data/jieket4dg/datafile/jieke_data.309.1067980347destination for restore of datafile 00025: /data/jieket4dg/datafile/ogg_tbs.312.1080748083channel ORA_DISK_1: reading from backup piece /data/backup/incre_1n0k3ibh_1_1channel ORA_DISK_1: piece handle=/data/backup/incre_1n0k3ibh_1_1 tag=TAG20220124T153407channel ORA_DISK_1: restored backup piece 1channel ORA_DISK_1: restore complete, elapsed time: 00:05:35
Finished recover at 2022-01-24 18:10:32
RMAN>

5、开库并启动 mrp0 应用日志

alter database open;ALTER DATABASE RECOVER MANAGED STANDBY DATABASE USING CURRENT LOGFILE DISCONNECT FROM SESSION;
set linesize 150; set pagesize 9999; column name format a13; column value format a20; column unit format a30; column TIME_COMPUTED format a30; select name,value,unit,time_computed from v$dataguard_stats where name in ('transport lag','apply lag');

[object Object]

6、ADG 其他常用 SQL

--1.查询主备库的同步情况set linesize 150;set pagesize 20;column name format a13;column value format a20;column unit format a30;column TIME_COMPUTED format a30;select name,value,unit,time_computed from v$dataguard_stats where name in ('transport lag','apply lag');
--备库查询alter session set nls_date_format='yyyy-mm-dd hh24:mi:ss';select THREAD#,count(FIRST_TIME) from v$archived_log where APPLIED='NO' group by THREAD#;select THREAD#,min(FIRST_TIME) from v$archived_log where APPLIED='NO' group by THREAD#;select THREAD#,min(SEQUENCE#) from v$archived_log where APPLIED='NO' group by THREAD#;select BACKUP_COUNT from v$archived_log where THREAD#=&1 and SEQUENCE#=&2;
--2.查询备库的进程状态SELECT PROCESS, STATUS,SEQUENCE#,thread# FROM V$MANAGED_STANDBY;
select MESSAGE_NUM,ERROR_CODE,TIMESTAMP,MESSAGE from v$dataguard_status;
--3.查询备库的角色set linesize 160;column DBNAME format a8;column DBUNAME format a10;column cftype format a8;column OPEN_MODE format a25;column DATABASE_ROLE format a18;select name dbname,db_unique_name dbuname,controlfile_type cftype,database_role,open_mode from v$database;
--4.查询备库的日志应用模式SELECT RECOVERY_MODE FROM V$ARCHIVE_DEST_STATUS WHERE DEST_ID=1;   RECOVERY_MODE---------------------------------------------------------------------MANAGED REAL TIME APPLYs
--5.开启日志应用进程：--应用stanby 实时同步SQL> ALTER DATABASE RECOVER MANAGED STANDBY DATABASE USING CURRENT LOGFILE DISCONNECT;
alter database recover managed standby database using current logfile disconnect from session; --6.取消日志应用ALTER DATABASE RECOVER MANAGED STANDBY DATABASE CANCEL;
set lines 320col message for a88col timestamp for a20SELECT ERROR_CODE, SEVERITY, MESSAGE,        TO_cHAR(TIMESTAMP, 'DD-MON-RR HH24:MI:SS') TIMESTAMP FROM V$DATAGUARD_STATUS WHERE CALLOUT='YES'AND TIMESTAMP > SYSDATE-1;
select THREAD#,sequence#, first_time, next_time, applied from v$archived_log order by 3;
select name,database_role,switchover_status from v$database;select sequence#, first_time, next_time, applied from v$archived_log order by sequence#;
col type for a15set lines 220set pages 330col item for a20col units for a15select to_char(start_time, 'DD-MON-RR HH24:MI:SS') start_time, type,       item, units, sofar, total, timestamp from v$recovery_progress;
--查看当前归档日志应用情况select a.thread#, b.max_available, a.max_applied, b.max_available-a.max_appliedfrom(select thread#, max(sequence#) max_applied from gv$archived_log where applied='YES' group by thread# ) a,(select thread#, max(sequence#) max_available from gv$archived_log group by thread# ) b where a.thread#=b.thread#;
select name,value,datum_time from v$dataguard_stats;

全文完，希望可以帮到正在阅读的你~~~
